Product Details:
|
| Arm Length: | 1100mm | Load Capacity: | 350 Kg |
|---|---|---|---|
| Column Length（L=1100mm): | 1 PC | Guideway Extension Arm（240x240mm): | 1 PC |
| Gas Socket （German Standard Import)（O2x1,Airx1,Vacx1): | 3 PCS | Multi-purpose Power Socket: | 6 PCS |
| Communication Socket RJ45: | 1 PC | Shelf(400*510mm): | 2 PCS |
| Stainless Steel Basket: | 1 PC | Height Adjustable Infusion Rack( Stainless Steel ): | 1 PC |
| High Light: | medical ceiling pendant,icu pendant |
||
Aluminum Alloy Electrical Hospital Endoscope Equipment Medical Pendant
Features Description
1. Pendant Applicative Area: Surgical Room/ Emergency Room/ICU/Recovery Room
2. Ceiling Mounted installed.Within 340°revolved,Adjustterminal box location,convience for medical staff operation.
3.The suspension arm is imported by high-strength aluminum alloy extrusion, surface designed by the first level oxidized rust prevention.
4. Friction brake + Pneumatic brake,adopted by German Standard Gas terminal(Insert and Pull more than 20,000 times.)
Combination pendant, then take care of its simple structure, easy to use ,is the ideal operating room medical gas supply ,the network load output termitnal and workstation equipment .
The installation of the hoisting of the way the use of smallpox that can 340 ° and configurations of pneumatic brakes Anti-drift, and its equipment can be high so that health care workers and staff ,handy, small and medium-sized hospital operating room of the medical auxiliary equipment indispensable.
SPECIFICATIONS
| Type | HFP-DD240/380 Medical Pendant(for Surgical ) Type 1 |
| The load capacity for Pendant | 350Kg |
| Column length | 1000mm |
| Arm | Double ,1100mm |
| Arm Rotating Angle | 340° |
| Braking System | Friction brake+gas brake |
| Medical Gas Outlets Standards | British,German,French,Metric, Ohmeda,DISS,Chemetron, Purit-Bennett Standards Optional |
STANDARD CONFIGURATION
| Medical Gas Outlets For O2 | 1 |
| Medical Gas Outlets For Vacuum | 1 |
| Medical Gas Outlets For Medical Air | 1 |
| Electric Socket | 6 |
| Equipment Shelves | 2 |
| Drawer | 1 |
| Stainless steel basket | 1 |
| Communication Socket RJ45 | 1 |
Delivery&Warranty
| Warranty | 1 year |
| Term | 100% T/T |
| Delivery | 7 days after payment received |
|
FAQ
Q1. Can I have a sample order for pendant?A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable. Q2. What about the lead time?A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than Q3. Do you have any MOQ limit for medical pendant order?A: 1 pc for sample checking is available |
