Product Details:
|
| Product Type: | Ultrasound Scanner | MOQ: | 1 SETS |
|---|---|---|---|
| Certification: | CE、FDA | ||
| High Light: | Color Doppler Ultrasound Scanner,USB Port Doppler Ultrasound Scanner,Multilingual Doppler Ultrasound Scanner |
||
* 96ele Probe
* 12 inch LED color display
*Support multi-lingual
* 16 GB Memory Card
* Battery 3-5 working hours
* USB port
* User Manual
* Aluminum case packing
| Displaying mode | B,B/B,4B,B/M,M, B/C,B/C/D,B/D, duplex, triplex, CFM, PW |
| Signal processing: | Full-digital beam forming, dynamic filter, dynamic real time receiving focusing, spectral processing, CFM processing, real-time dynamic focusing, dynamic aperture in all fields |
| Image processing: |
THI Storage: 16G Power adjustable Smoothing function Edge enhancement One-key optimization Image conversion Wall filter adjustable Base line adjustable PRF adjustable AIO-Auto image optimization IZoom: Instant full screen image I-Image: intelligent optimization MBF: Multi Beam Former SA: Synthetic Aperture Ultrasonic imaging Iclear: Speckle Noise Reduction CDF: Contunuous Dynamic Focusing |
| General measurement | Normal, MSK, ABD, OB, Pelvic,Urology, Cardiac, Small Parts, Vascular |
| Normal measurement | Volume, V3L, STD_S, Area Trace,Mtime, MHR, D Time, DV, D Common, D Auto, Area, Angle, CrossLine, STD D, ParalleLine, Mdist,MV, D HR, DA, D Trace |
| ABD packages | ABD, Aorta, R_Kidney & L_Kidney, Bladder, Prostate |
| OB Packages | Early_OB, Rt-Ovary, Lt-Ovary, Uterus, Fetal_Biome, Long_Bones, AFI |
| Pelvic Packages | Uterus, Rt/Lt - Ovary, Rt/Lt-Follicle, |
| Urology packages | Rt/Lt- kidney measurement, Bladder, Prostate,Rt/Lt_Testicle |
| Small Parts | Rt/Lt_Thyroid, Rt/Lt_Testicle, Vessel, Breast |
| Vascular | Stenosis D, senosis A, Intima, Arterial, Venous |
| MSK | Distance, Area, Hip_Angle |
| Scanning depth | ≥250mm |
| Standard Configuration | Main unit, 12 inch LED monitor, 3.5Mhz convex probe, 7.5Mhz linear probe, 2 Probe connectors, User’s Manual, hard disk (SSD) |
| Options | 6.5Mhz Transvaginal Probe, 3.5Mhz Micro-convex Probe, Trolley, Printers, Biopsy kit,Aluminum case |
THI
Storage: 16G
Power adjustable
Smoothing function
Edge enhancement
One-key optimization
Image conversion
Wall filter adjustable
Base line adjustable
PRF adjustable
AIO-Auto image optimization
IZoom: Instant full screen image
I-Image: intelligent optimization
MBF: Multi Beam Former
SA: Synthetic Aperture Ultrasonic imaging
Iclear: Speckle Noise Reduction
CDF: Contunuous Dynamic Focusing
