Product Details:
|
| Name: | DR X-Ray Machine | Application: | X-Ray Room |
|---|---|---|---|
| Power Supply: | 220V/110V | MOQ: | 1 SETS |
| Function: | Medical Diagnosis | ||
| High Light: | 100kV Radiographic Medical X Ray Equipment,2800r/Min Medical X Ray Equipment,30kHz Radiographic X Ray Equipment |
||
Product Configuration:
1.X-ray tube 2.Collimator 3. Radiographic table 4.High voltage generator
5.Micro console 6.High voltage cable 7.Double Grid 8.Vertical bucky stand
1. Main Technical Parameters
(1) Function: Radiography
(2) X-ray machine maximum output power:
Intermittent mode 100kV ,500mA,50kW
(3) Range of x-ray tube current:16mA~630mA
Range of x-ray tube voltage:40kV~125kV
(4) Exposure time: 0.0025s~6.3s
(5) Nominal working frequency≥30kHz
(6) Power supply: Three-phase five wires 380V±38V
2. Main configuration
(1) High frequency high voltage generator
(including control console)
(2) X-ray tube
Focus :small focus:1.0mm large focus:2.0mm
Anode speed: 2800r/min
Anode thermal capacity: 140KHU
(3) Collimator power supply: ac 24V
(4) Radiography bed
a. Single phase 220V±22V,50Hz±1Hz
b. X-ray components supporting frame
Braking mode: Electromagnetic brake, braking force ≥98 N, button operation
Filter: N40.r10.f0=180cm, stationary type,
size: 5″×7″ 8″×10″ 10″×12″ 11″×14″ 14″×17″
C.Size: L2000mm×W760mm×H685mm
Vertical moving range: ≥825mm
Horizontal moving range: ≥250mm
